Roj Hmab Kneader
Roj hmab kneader tau siv dav hauv cov chaw tsim khoom log, nws haum rau sib xyaw yuav luag txhua yam khoom siv roj hmab.
Khoom nta:
1. Roj hmab lossis yas thiab lwm yam khoom xyaw tuaj yeem sib xyaw lossis ua yas hauv qhov kaw, ua kom muaj zog thiab tswj tau qhov kub thiab txias, kom cov khoom lag luam tsim tawm siab, cov khoom tawg yooj yim yog qhov zoo thiab cov khoom lag luam zoo.
2. Sib tov chav, rotors thiab rams yog txhua tus siv lub tsho qauv, yog li cov pa, roj lossis dej tuaj yeem raug txhaj rau cua sov lossis lub hom phiaj txias, kom haum rau qhov sib txawv thev naus laus zis xav tau ntawm kev sib xyaw roj hmab lossis yas ua kom huv.
3. Kev tsim ntawm lub kaum ntse ntse thiab qhov ntev ua haujlwm ntawm rotor tav yog qhov tsim nyog, uas tuaj yeem ua rau cov khoom tau txais qhov xav tau sib xyaw ua ke. Lub rotor peaks thiab lub ntsej muag kawg yog ua los ntawm cov tawv tawv tiv taus tawv tawv. Cov nplaim sib xyaw ua ke, rotor, thiab ram ncaj qha tiv tauj nrog cov khoom siv yog txhua yam polished tom qab phaj nrog nyuaj chrome, uas yog qhov ci, hnav-tiv taus thiab tiv taus xeb.
4. Txais cov khoom siv rov qab lub qhov rooj pub mis, sib tov chav tso tawm lub qhov rooj tuaj yeem siab tshaj 140 ° tig, qhov kev tsim qauv no ua kom yooj yim txheej txheem kev tsim khoom txuas ntxiv, tseem yog qhov yooj yim rau kev saib xyuas thiab ntxuav ntawm chav sib xyaw thiab rotors.
5. Tilting mechanism txais yuav lub hnab ntim toroid cab iav tsav (TOP) nrog kev ua haujlwm siab thiab muaj peev xwm thauj khoom loj, yog li ntawd tuaj yeem paub lub tshuab tsis nres nres, zam kev nquag pib ntawm lub cav, thiab txuas ntxiv nws cov kev pab cuam lub neej.
6. Lub kaw lus tswj hluav taws xob siv PLC tswj, uas tuaj yeem ua tiav kev ntseeg siab tsis siv neeg saib xyuas, tswb, tiv thaiv kev tiv thaiv thiab lwm yam haujlwm.
Peb tau mob siab rau muab qhov sib txawv ntawm cov roj hmab kneaders rau peb cov neeg tau txais txiaj ntsig nrog ntau yam tshwj xeeb thiab ua tau zoo, ua tiav cov kneader los ntawm lab mus rau 150 litres tuaj yeem ua tau. Lub tshuab no tau siv dav hauv kev lag luam roj hmab thiab yas, zoo li lub log tsheb lub Hoobkas, lub tshuab xa khoom siv, lub Hoobkas caij nplooj ntoo hlav, lub raj xa hluav taws xob, lub tshuab fais fab cable, thiab lwm yam.
Yog tias koj xav tau lub tshuab sib xyaw nrog pob nyiaj siv tsawg, roj hmab kneader yog qhov kev xaiv zoo.
Qauv | X(S)N-35x30 | X(S)N-55x30 | X(S)N-75x30 | X(S)N-110x30 | X(S)N-150x30 |
Tag nrho ntim ntawm chav sib xyaw (L) | 75 | 125 | 180 | 250 | 325 |
Ua haujlwm ntim ntawm chav sib xyaw (L) | 35 | 55 | 75 | 110 | 150 |
Tsav lub zog tsav (kw) | 55 | 75 | 110 | 185 | 220 |
Kev sib hloov ceev ntawm rotor (pem hauv ntej/ nram qab) (r/ min) | 30/24.5 | 30/24.5 | 30/24.5 | 30/24.5 | 30/24.5 |
Tilting kaum degree (°) | 140 | 140 | 140 | 140 | 140 |
Tilting lub cev muaj zog zog (Kw) | 2.2 | 2.2 | 4 | 4 | 5.5 |
Siab ntawm huab cua compressed (Mpa) | 0.5-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
Siab ntawm cov dej txias (Mpa) | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 |
Siab ntawm cua sov ua kom sov (sib xyaw yas) (Mpa) | 0.5-0.8 | 0.5- 0.8 | 0.5-0.8 | 0.5-0.8 | 0.5-0.8 |
Qhov ntev (LxWxH) (hli) | 3200 x 1900 | 3280x 1930 | 3330x2620 | 3930x3000 | 4200x3300 |
Qhov hnyav tag nrho (t) | ~6.3 | ~7.5 | ~10.3 | ~14.2 | ~19.5 |
1. Muab cov lus pom zoo tshaj plaws raws li qhov xav tau tshwj xeeb.
2. Ua raws thiab xa cov ntaub ntawv tsim khoom tshiab rau peb cov neeg tau txais txiaj ntsig raws sijhawm.
3. Lub tshuab xa khoom raws sijhawm nrog cov rooj ntoo yog tias cov neeg siv khoom xav tau, xyuas kom tsis txhob ya raws thiab tiv thaiv xeb pob.
4. Kev teeb tsa txawv teb chaws lossis kev qhia hauv online tuaj yeem muab tau.
5. Ib xyoo lav rau cov tshuab, thiab tus nqi zoo tshaj rau cov khoom seem.
6. Kev pab cuam tom qab muag zoo. Txhua lo lus nug thaum siv lub tshuab, peb ib txwm nyob ntawm no thiab muab lus teb rau koj sai.
